KONFORT 780 DUAL GAS TOUCH

Both R134a & R1234yf in one machine

KONFORT 780 DUAL GAS (R134a and R1234yf)

Our flagship Konfort. The machine allows users to alternate
services on vehicles equipped with R134a and R123yf refrigerants.

The Konfort 780 DUAL GAS has two tanks and two separate circuits for recovery, recycling and recharging.

The machine is fully automatic and the operator can switch from one refrigerant to the other within few minutes thanks to the automatic refrigerant detection.

A large display for great results

The KONFORT TOUCH machines are equipped with a 10-inch colour multi-touch screen display which gives them great usability and allows a clear view of the operations to perform.

The innovative graphic interface has been developed to ensure a really intuitive software user experience, making it easier to quickly read the data displayed.

Data reading is best supported by the high resolution and 400 nits brightness.

An interesting feature is also the possibility for the operator to choose between a light or dark theme
for the background.

The display on the KONFORT TOUCH stations features the glove-touch technology, which ensures perfect use while wearing different types of work gloves.

Many connection modes

The machine has Wi-Fi connectivity for a series of activities, such as:
– printing reports in a larger format;
– receiving software and firmware updates in real time;
– receiving remote technical assistance;
– connecting to the myTEXA portal;
– connecting with the KONFORT Mobile APP.

The Bluetooth module lets the user connect the machine with an external printer.

The stations are also equipped with a practical USB port, which can be used to back up the reports of the services
performed and the entire system.

KONFORT APP

Thanks to a dedicated APP, the TEXA Konfort machines communicate with Android and iOS smartphones.

The operator can follow the progress of the service and charging procedures remotely. The APP will alert the operator in case of issues or faults and when the service is complete.

The Android operating system makes everything easier and faster

The KONFORT machines are engineered to be extremely user friendly and achieve the maximum
simplification of the maintenance and charging operations.

To reach this goal TEXA opted for an Android 10 embedded operating system. This choice grants ease of use and a very intuitive layout with several infographics.

The software updates are performed automatically and securely.

Simple and intuitive user interface
to improve efficiency

The interface is designed to provide all the necessary information in a single screen; this way, users can have
direct access to the most useful operations. In next to no time, you will move from the initial station activation
phases to carrying out the service.

Three different service options:

– US CARS DATABASE – Vehicle M/M Selection
– CUSTOMIZED SERVICE – Manually Enter Quantity
– myDATABASE – Create Your Own Database

The menu, which can be browsed really easily, makes the most of the large display and reduces the “steps”
required to start a charging service. Moreover, the search mode “Smart selection by model” allows you to find
the vehicle you are working on by simply entering one or more keywords.

Below is an overview of the main software screens, from the service selection to the charging phases and the
remote after-sales assistance request:

Smart selection by model

Enter a keyword in order to find more rapidly the vehicle you wish to work on. It also works with words in proximity.
All the operating parameters can be set in a single screen.

«Recovery» phase

The screen highlights the time remaining until the refrigerant recovery operation is complete.

«Vacuum» phase

A vacuum is induced in the vehicle’s A/C system to check for possible leaks.

«Refrigerant charge» phase

The station charges the correct amount of gas into the vehicle system.
Once the operation is complete, the report is saved automatically and can be printed as you prefer.

Example of a detected error

KONFORT TOUCH has detected a failure, in this case the amount of refrigerant is not enough.

Online technical assistance

The operator of a KONFORT TOUCH machine can  count on constant after-sales assistance.

Simply connect the station to the workshop’s Wi-Fi network, access the Applications page from the software interface and select Remote Assistance.

From this page it is possible to let a specialized technician take control of the KONFORT remotely to perform maintenance activities or test components.

For example, the technician can activate the machine, check its operating status or troubleshoot errors, calibrate the scales, check the solenoid valves.. and much more!

Production and quality certified
ISO TS 16949 quality system

The KONFORT TOUCH range benefits from new developments in materials, technologies and automated
production procedures that resulted in TEXA gaining an ISO TS 16949 certification.

All phases are subject to strict quality control, from component selection and development to machining, assembly,
distribution and after-sales service.

After assembly, the stations enter the testing department where the electrical system is tested and the scales
sensors and pressure transducers are calibrated. Functional testing is then performed to verify that all components
and devices respond correctly and perform according to specifications.

Rigorous testing eliminates the risk of defects in the hydraulic system and ensures that all parts are effectively
sealed. The final stage of testing takes place in a special sealed chamber and involves the injection of helium into
the tank and the recharge circuit. Helium is used because its particularly small molecules are able to find even
minute leaks.

The KONFORT charging stations conform to European CE/PED safety standards, to the American standards
governing refrigerant purity (SAE J2099 for both R134a and R1234yf) and to those governing efficiency in the
recovery of at least 95% of used refrigerant (SAE J2788 for R134a and SAE J2843 for R1234yf).

Specific training*

for A/C servicing

TEXA believes offering customer training to be particularly important. Adequate technical competence and
the correct use of diagnostic tools are critical to the success of a workshop business.
The teaching methods used in TEXA courses are based on an ideal mix of theory and practical elements.

Practice plays a fundamental part, as it combines testing and simulations with use of the technicians’ own TEXA
diagnostic tools, thus stimulating a more active and dynamic participation and effective learning.

*Verify the availability of TEXAEDU in your own country.

AC-307/2008:
REFRIGERANT HANDLING

AC-307/2008:
REFRIGERANT HANDLING

AIM:
Acquire all the minimum knowledge and know-how required by Reg. 307/2008. All vehicle repairers that carry out recovery activities of the R134a gas from a motor vehicle’s A/C system must obtain the qualification to use such gas by attending a training course organised by a Certified organisation. Following the DPR (Decree of the President of the Italian Republic) no.146/2018, the F-gas database was created for the registration of companies and people that purchase F-gas and therefore must both comply with the subscription and be qualified. TEXA has certified its training course, in compliance with the contents of the DPR (Decree of the President of the Italian Republic) no.43/2012, and equipped all its training centres in Italy according to the characteristics required by the Decree.

DURATION:
8 hours (available also online)

G16C:
MAINTENANCE AND DIAGNOSTIC TECHNIQUES OF THE NEW A/C SYSTEMS WITH THE R1234YF AND R744 GASES

G16C:
MAINTENANCE AND DIAGNOSTIC TECHNIQUES OF THE NEW A/C SYSTEMS WITH THE R1234YF AND R744 GASES

AIM:
Learn the key points of the European legislation and the technical properties of the new R1234yf and R744 refrigerants. Know how to service cooling systems with the R1234yf and R744 gases and learn the requirements for the storage and the procedures for recharging and servicing in complete safety. Know how to carry out the recovery, recycling and recharging procedures correctly with the R1234yf and R744 gases through two examples on a Toyota Prius and Mercedes-Benz.

DURATION:
8 hours

Prodotto da inserire all’interno del sistema per il trattamento dei gas di climatizzazione di autoveicoli KONFORT.
Verificare con il proprio rivenditore TEXA di fiducia le modalità di accesso al Nuovo Piano Industria 4.0.

Technical Specifications

TECHNICAL SPECIFICATIONS:

  • Dual refrigerant management R134a and R1234yf
  • Fully automatic service management
  • Refrigerant identifier
  • Automatic leak detection
  • Refrigerant quantity measurement with electronic scales
  • Recovered oil quantity measurement with electronic scales
  • Hybrid vehicle compatible
  • Automatic service management (DATABASE)
  • Customized service management
  • FPS security system (Fan Protection System)
  • Flushing system for refrigerant change
  • Flushing system for oil change
  • Printout of completed services via Wi-Fi
  • 10” touchscreen display
  • Compatibility with KONFORT APP
  • Two Separate 20LB Tanks
  • Charging accuracy +/- 15 g
  • Highest Efficiency – Recovery Over 97%
  • Two-stage vacuum pump
  • Scales locking system
  • Operating mode: DATABASE
  • Operating mode: CUSTOMIZED SERVICE
  • Operating mode: MY DATABASE
  • Multi-language software
  • Automatic service hose length compensation
  • Automatic maintenance alarm
  • Simplified maintenance
  • Automatic management of non-condensable gases
  • Remote assistance
  • Automatic updates

OPTIONAL:

  • Leak detection kit with Forming Gas
  • Thermal printer

WARRANTY
2 years
